7251 / 7351 Slide Gate Operator
INSTALLATION AND PROGRAMMING MANUAL
4
7251 / 7351 SYSTEM SPECIFICATIONS
MODEL 7251 - POST MOUNT 7351 - PAD MOUNT
ENCLOSURE (W x H x D)
22 x 22 x 15.5 inches
(56 x 56 x 39.4 cm)
20.5 x 26.5 x 18 inches
(52 x 67.3 x 45.7 cm)
DUTY CYCLE Varies based on charging capacity
DRIVE Electro-mechanically driven chain
RATE OF TRAVEL 1 ft/sec (30 cm/sec.)
GATE LENGTH MAX. 25 ft (7m)
GATE WEIGHT MAX. 800 Lb (362 kg)
TEMPERATURE RATING -4º to 122º F (-20º to 50º C)
OPERATING VOLTAGE 12VDC
INPUT VOLTAGE Main DC power in: 10-35 VDC, solar in: 10-35 VDC, 30A Max.
IDLE CURRENT 10mA
ACCESSORY POWER 3A
USER CONTROLS 1050 control board (open, stop, close, reset)
FINISH Powder coated black
SENSOR TYPE INPUTS Edge, photo eye, and ground loops
BATTERY POWER 12 or 24 VDC
INCLUDED SENSORS Photo eye TX/RX through beam pair
ACCESSORY CONNECTORS
Power, mag lock, lamp, alarm, loops, edge, exit, guard station,
Fire, BlueBUS
RELAYS Two programmable relays
UL 325 CERTIFICATION Usage class I, II, III, IV
www.ApolloGateOpeners.com | (800) 878-7829 | Sales@ApolloGateOpeners.com
