7251 / 7351 Slide Gate Operator
INSTALLATION AND PROGRAMMING MANUAL
75
7251 POST MOUNT CHASSIS, PARTS, AND 1050 CONTROL BOARD
This drawing is a representation and should be used for parts reference only.
Chain Cover
Idler Sprocket
1050 Circuit Board
OXI/A Receiver
Limit Sub Assembly
7251 control box
Lid, Control Box
Bearing, Flange
Sprocket, Limit - Quick
Release
Sprocket, Quick Release
Quick Release
Sprocket, Drive, #40
Chain, 13 Tooth
