TECHNICAL SPECIFICATIONS
11
12 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A.
reserves the right to apply modications to the product at any time when deemed necessary, without altering
its functions and intended use.
Table 18
TECHNICAL SPECIFICATIONS
Description Technical specication
M3BAR M5BAR M7BAR L9BAR
Product type
Boom gate for residential use inclusive of electronic control unit
Clear opening (m)
2,32 ÷ 2,82 3,17 ÷ 4,82 5 ÷ 7 7 ÷ 9
Start peak torque (Nm)
100 200 300 400
Start peak torque (Nm)
30 70 90 130
Manoeuvre time (adjustable in sec)
2,5 - 4 3 - 6 6 - 10 8 - 12
Maximum frequency of operating
cycles/hour at nominal torque (the
control unit limits the cycles to the
maximum shown in Table T3)
500
continuous use
350
continuous use
200 150
Durability Refer to the “Product durability” paragraph
Power supply 230VC 50/60Hz
Power supply voltage /V1 230VC 50/60Hz
Maximum power draw at peak (W)
150 110 110 160
Maximum power at nominal torque
(W)
40 50 40 50
Insulation class
1
Emergency power supply
With optional accessory PS224
Photovoltaic power supply
With optional accessory SYKCE
FLASH output
for 1 LUCYB, MLB or MLBT warning light (12 V – 21 W)
LIGHT output
for XBA4 “boom lights” optional accessory
OGI output
for 24 V (max 10 W) indicator light
Output for warning light / trafc light
on cover
with XBA7 LED warning light or XBA8 LED trafc light optional accessories
BLUEBUS output
One output with maximum load of 10 BlueBus units
STOP input
For normally closed or normally open contacts or for 8.2 kΩ xed resistor contacts with self-
learning (any variation from the memorised status triggers the STOP command)
Sbs input
For normally open contacts
OPEN input
For normally open contacts
CLOSE input
For normally open contacts
HP SbS input
For normally open contacts
Radio connector
SM connector for SMXI and SMXIS receivers
Radio ANTENNA input
50 Ω for RG58-type cable or similar
Inputs for metal detectors
2
Programmable functions
Refer to the “PROGRAMMING” chapter and additional settings via the Oview Programming
and Control Unit
Self-learning functions
Self-learning of the devices connected to the BlueBus output
Self-learning of the type of “STOP” device (Normally Open, Normally Closed contact or 8.2
kΩ resistor)
Learning of the door opening and closing positions
Operating temperature
-20°C ÷ 55°C
Use in highly acid, saline or
potentially explosive atmosphere
No
Protection rating
IP54
Dimensions and weight
400x299x1215h mm;
80 kg
400x299x1215h mm;
80 kg
400x299x1215h mm;
85 kg
500x299x1215h mm;
98 kg

Nice M5BAR Specifications
