Mercury 310 Automated Gate System
Installation and Programming Manual
7171
TITAN 912L Linear Actuator Manual Release
TITAN 912L Linear Actuator
1. Lift up the rubber key cap (See illustration below).
2. Insert key and turn 90° clockwise.
3. Lift up the mechanical release.
4. After mechanical release is opened, the actuator arm can now be freely extended, and
the gate can now be moved by hand.
5. To re-enable the actuator, reverse the above instructions.
2 31
CAUTION
While it is entirely possible to use the gate system with the TITAN 912L actuator
unlocked, it is inadvisable in oder to ensure security and safety. Be sure to store
the actuator key in a secure place that will be remembered when needed.
Mercury 310
www.ApolloGateOpeners.com | (800) 878-7829 | Sales@ApolloGateOpeners.com
