TITAN 912L Linear Actuator
Installation Reference Manual
1313
8
RUN ACTUATOR CABLE(S) TO CONTROL BOX
Run the cable of the actuator closest to the control box through a hole (with rubber grommet) drilled in the
bottom on the control box. If necessary, entry may be made elsewhere on the control box.
If a dual gate installation:
1. Dig a trench across the driveway deep enough to accomodate the longer harness cable from the actuator
farthest from the control box.
2. Run the cable through a conduit and lay this in the trench.
3. Cover the trench and use asphault patch if needed.
4. Run the 2nd cable into a hole (with rubber grommet) in the bottom of the control box.
4.2 RUN ACTUATOR CABLE(S) TO CONTROL BOX
NOTICE
Ensure cables reach into the control box sufciently to reach the MOTOR inputs on the control board.
www.ApolloGateOpeners.com | (800) 878-7829 | Sales@ApolloGateOpeners.com
