Unidrive M/HS Frame 5 to 6 Power Installation Guide 101
Issue Number: 9
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
5.1.25 Electromagnetic compatibility (EMC)
This is a summary of the EMC performance of the drive. For full details, refer to the EMC Data Sheet
which can be obtained from the supplier of the drive.
Table 5-30 Immunity compliance
*
See section 4.12.6 Variations in the EMC wiring on page 79 for possible requirements regarding
grounding and external surge protection of the control ports.
Standard
Type of
immunity
Test specification Application Level
IEC 61000-4-2
EN61000-4-2:2009
Electrostatic
discharge
6 kV contact discharge
8 kV air discharge
Module enclosure
Level 3
(industrial)
IEC 61000-4-3
EN61000-4-3:2006+A2:2010
Radio frequency
radiated field
10 V/m prior to
modulation
80 - 1000 MHz
80 % AM (1 kHz)
modulation
Module enclosure
Level 3
(industrial)
IEC61000-4-4
EN61000-4-4:2012
Fast transient
burst
5/50 ns 2 kV transient at
5 kHz repetition
frequency via coupling
clamp
Control lines
Level 4
(industrial harsh)
5/50 ns 2 kV transient at
5 kHz repetition
frequency by direct
injection
Power lines
Level 3
(industrial)
IEC61000-4-5
EN61000-4-5:2014
Surges
Common mode 4 kV
1.2/50 s waveshape
AC supply lines:
line to ground
Level 4
Differential mode
2 kV1.2/50 s waveshape
AC supply lines:
line to line
Level 3
Lines to ground
Signal ports to
ground
*
Level 2
IEC61000-4-6
EN61000-4-6:2014
Conducted radio
frequency
10V prior to modulation
0.15 - 80 MHz
80 % AM (1 kHz)
modulation
Control and power
lines
Level 3
(industrial)
IEC61000-4-11
EN61000-4-11:2004
Voltage dips and
interruptions
-30 % 10 ms
+60 % 100 ms
-60 % 1 s
<-95 % 5 s
AC power ports
IEC61000-6-1
EN61000-6-1:2007
Generic immunity standard for the
residential, commercial and light - industrial
environment
Complies
IEC61000-6-2
EN61000-6-2:2005
Generic immunity standard for the industrial
environment
Complies
IEC61800-3
EN 61800-3: 2004+A1:2012
Product standard for adjustable speed power
drive systems (immunity requirements)
Meets immunity requirements for first
and second environments
