100 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Table 5-8 Losses @ 50° C (122° F) ambient
Model
Normal Duty Heavy Duty
Drive losses (W) taking into account any
current derating for the given conditions
Drive losses (W) taking into account any current
derating for the given conditions
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
07200610 538 570 597 650 703 710 717 430 466 488 532 575 581 587
07200750 678 718 751 799 750 758 765 526 570 597 650 654 661 667
07200830 848 898 898 805 751 759 766 585 634 663 705 653 660 666
08201160 1353 1433 1536 1741 1770 1788 1806 1020 1105 1193 1228 1277 1290 1303
08201320 1640 1737 1740 1759 1771 1789 1807 1110 1202 1206 1228 1278 1291 1304
09201760 (9A) 2028 2170 2312 2354 2256 2010 1910 1580 1701 1822 1943 1867 1757 1700
09202190 (9A) 2431 2405 2368 2358 2245 2015 1922 2016 2063 2029 1954 1868 1763 1701
09201760 (9E) 1889 2031 2174 2240 2172 1970 1889 1488 1609 1730 1862 1808 1728 1684
09202190 (9E) 2241 2239 2223 2243 2161 1975 1900 1874 1932 1916 1872 1810 1733 1686
10202830 2478 2625 2641 2625 2671 2490 2379 2068 2240 2375 2326 2271 2185 2141
10203000 2666 2629 2643 2629 2678 2495 2374 2213 2394 2375 2350 2275 2187 2141
400 V
07400660 744 830 907 1062 1141 1152 1164 616 692 758 751 725 732 740
07400770 895 999 1087 1163 1138 1149 1161 720 808 804 779 773 781 789
07401000 1018 1136 1200 1118 1074 1085 1096 821 922 878 838 828 836 845
08401340 1480 1652 1815 2016 1970 1990 2010 1256 1410 1392 1391 1432 1446 1461
08401570 1754 1957 2114 1998 1979 1999 2019 1393 1564 1539 1518 1531 1546 1562
09402000 (9A) 2431 2710 2872 2799 2737 2639 2652 2132 2136 2290 2289 2305 2342 2399
09402240 (9A) 2837 2926 2870 2814 2737 2660 2665 2286 2294 2300 2294 2300 2340 2404
09402000 (9E) 2286 2565 2738 2709 2675 2611 2638 2014 2039 2200 2228 2262 2322 2389
09402240 (9E) 2648 2760 2735 2723 2675 2632 2651 2152 2184 2209 2233 2258 2320 2394
10402700 3210 3582 3681 3765 3700 3597 3591 2604 2923 3105 3081 3125 3165 3262
10403200 3482 3598 3676 3776 3694 3625 3589 3018 3062 3105 3087 3131 3168 3300
575 V
07500440 936 988 1115 1225 1144 1155 1167 705 817 923 923 898 907 916
07500550 1161 1225 1228 1098 1030 1040 1051 797 923 914 828 809 817 825
08500630 1753 1850 2172 2540 2672 2699 2726 1161 1345 1585 2292 2242 2264 2287
08500860 1980 2090 2291 2540 2684 2711 2738 1593 1845 2029 2039 2047 2067 2088
09501040 (9A) 1707 1977 2247 2538 2456 2495 2699 1372 1601 1830 2139 2122 2258 2455
09501310 (9A) 2087 2410 2734 2544 2456 2482 2676 1752 2034 2222 2143 2128 2258 2453
