Unidrive M / HS Frame 7 to 10 Power Installation Guide 103
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-10 IP Rating degrees of protection
Table 5-11 UL enclosure ratings
5.1.10 Corrosive gasses
Unidrive M600 to M702:
Concentrations of corrosive gases must not exceed the levels given in:
• Table A2 of EN 50178:1998
• Class 3C2 of IEC 60721-3-3
This corresponds to the levels typical of urban areas with industrial activities and/or heavy traffic, but
not in the immediate neighborhood of industrial sources with chemical emissions.
Unidrive M200 to M400:
Concentrations of corrosive gases must not exceed the levels given in:
• Table A2 of EN 50178:1998
Printed Circuit Board & Component Solder technology of M200-400 are conformal coated to survive
environments as described by IEC60721-3-3 3C3 and EN60068-2-60 Meth. 4. This corresponds to
the levels typical of urban areas with industrial activities and/or heavy traffic and in the immediate
neighborhood of industrial sources with chemical emissions.
5.1.11 RoHS compliance
The drive meets EU directive 2011/65/EU for RoHS compliance.
5.1.12 Vibration
Maximum recommended continuous vibration level 0.14 g r.m.s. broad-band 5 to 200 Hz.
First digit Second digit
Protection against foreign bodies and access to
hazardous parts
Protection against ingress of water
0 Non-protected 0 Non-protected
1
Protected against solid foreign objects of 50
mm and greater
(back of a hand)
1 Protected against vertically falling water drops
2
Protected against solid foreign objects of
12.5mm  and greater
(finger)
2
Protected against vertically falling water drops
when enclosure tilted up to 15 °
3
Protected against solid foreign objects of 2.5
mm  and greater (tool)
3 Protected against spraying water
4
Protected against solid foreign objects of
1.0mm  and greater (wire)
4 Protected against splashing water
5 Dust-protected (wire) 5 Protected against water jets
6 Dust-tight (wire) 6 Protected against powerful water jets
7- 7
Protected against the effects of temporary
immersion in water
8- 8
Protected against the effects of continuous
immersion in water
UL rating Description
Type 1
Enclosures are intended for indoor use, primarily to provide a degree
of protection against limited amounts of falling dirt.
Type 12
Enclosures are intended for indoor use, primarily to provide a degree
of protection against dust, falling dirt and dripping non-corrosive
liquids.
