30 Unidrive M / HS Frame 7 to 10 Power Installation Guide
3.4.3 Through-panel mounting
The drive can be through panel mounted using appropriate brackets.
Figure 3-8 Through-panel mounting dimensions (size 7 to 10)
310 mm (12.20 in)
252 mm (9.92 in)
220 mm (8.66 in)
Æ9 mm (0.35 in)
x 6 holes
278 mm (10.95 in)
488 mm (19.21 in)
538 mm (21.18 in)
27.1 [1.066]
328 mm (12.91 in)
287±1 mm (11.3±0.04 in)
259 mm (10.20 in)
794 mm (31.26 in)
730 mm (28.74 in)
240 mm (9.45 in)
240 mm (9.45 in)
146 mm
(5.75 in)
Æ9 mm (0.35 in)
(4 holes)
166 mm
(6.54 in)
240 mm (9.45 in)
240 mm (9.45 in)
32 mm
(1.26 in)
Æ5. mm (0.21 in)5
(6 holes)
252 mm (9.92 in)
n5.5 typ.
8 places
989.8
259 mm (10.20 in)
287±1 mm (11.3±0.04 in)
327 mm (12.87 in)
883 mm (34.76 in)
586 mm (23.07 in)
406 mm (15.98 in)
231 mm (9.09 in)
Æ
9.0 mm (0.35 in)
x 4 holes
Æ
5.5 mm (0.22 in)
x 8 holes
1051 mm (41.38 in)
863 mm (33.98 in)
566 mm (22.28 in)
386 mm (15.20 in)
211 mm (8.31 in)
31 mm
(1.22 in)
328 mm (12.90 in)
287±1 mm (11.3±0.04 in)
259 mm (10.18 in)
Æ9 mm (0.35 in)
x 4 holes
Æ5 mm (0.21 in).5
x 8 holes
1058 mm (41.66 in)
923 mm (36.33 in)
714 mm (28.10 in)
471 mm (18.54 in)
211 mm (8.30 in)
32 mm
(1.24 in)
231 mm (9.09 in)
491 mm (19.32 in)
734 mm (28.89 in)
942 mm (37.08 in)
7
8
9E/10E
9A
