Unidrive M/HS Frame 5 to 6 Power Installation Guide 85
Issue Number: 9
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-5 Maximum permissible continuous output current @ 40 °C (104 °F) ambient with
high IP insert installed
Model
Normal Duty Heavy Duty
Maximum permissible continuous output current (A)
for the following switching frequencies
Maximum permissible continuous output current (A)
for the following switching frequencies
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
05200250 25.5 25.2 24.9 24.3 23.7 22.5 21.6 25.0 24.8 24.3 23.8 22.5 20.0
400 V
05400270 17.1 15.6 14.4 12.6 11.4 9.6 8.7 17.3 15.7 14.6 12.7 11.3 9.7 8.6
05400300 19.8 19.5 18.9 17.7 16.4 14.0 11.8 19.8 19.5 18.9 17.7 16.2 13.8 11.7
575 V
05500030 3.9 3.0
05500040 6.1 4.0
05500069 10.0 6.9
