86 Unidrive M/HS Frame 5 to 6 Power Installation Guide
Issue Number: 9
Table 5-6 Maximum permissible continuous output current @ 50 °C (122 °F)
Model
Normal Duty Heavy Duty
Maximum permissible continuous output current (A)
for the following switching frequencies
Maximum permissible continuous output current (A)
for the following switching frequencies
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
05200250 30 29.7 25.2 21.6 25 23 19.8 17.3
06200330 50 49 38 30 33 29 24.6
06200440 58 56 49 38 30.2 44 41 36 29 24.6
400 V
05400270 25.5 23.6 20.4 15.6 12.3 24 23.5 21.6 18.6 16.2 12.7 10
05400300 25.5 23.6 15.9 12.3 24 21.9 19.2 13.8 10.5
06400350 38 37 28 21.4 35 32 27 21 16.5
06400420 48 43 36.5 27.4 21.4 42 38 32 27 21 16.5
06400470 63 58 52 43 37 28 21.4 47 42 38 32 27 21 16.5
575 V
05500030 3.9 3.0
05500040 6.1 4.0
05500069 10 6.9
06500100 12 10
06500150 17 13.4 15 14 10.3
06500190 22 17.8 13.4 19 14 10.3
06500230 27 23.5 17.8 15 23 21.6 19 14 11.5
06500290 34 28.2 23.5 18 15 29 27.3 22 19 14 11.6
06500350 43.0 41.7 36.1 28 23.7 18 15 35 31.2 27.3 21.8 19 14 11.6
55 C ratings are available on request.
NOTE
