Unidrive M/HS Frame 5 to 6 Power Installation Guide 89
Issue Number: 9
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-9 Losses @ 50° C (122° F) ambient
Table 5-10 Power losses from the front of the drive when through-panel mounted
5.1.4 Temperature, humidity and cooling method
Ambient temperature operating range:
- 20 °C to 55 °C (- 4 °F to 131 °F).
Output current derating must be applied at ambient temperatures >40 °C (104 °F).
Cooling method: Forced convection
Maximum humidity: 95 % non-condensing at 40 °C (104 °F)
Model
Normal Duty Heavy Duty
Drive losses (W) taking into account any current
derating for the given conditions
Drive losses (W) taking into account any current
derating for the given conditions
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
05200250 280 291 302 324 341 325 312 236 245 254 272 268 261 264
06200330 375 394 413 452 480 431 594 264 277 290 316 342 346 352
06200440 442 463 484 510 483 432 451 350 366 382 389 369 341 353
400 V
05400270 251 275 300 326 326 328 330 245 255 257 262 268 277 274
05400300 244 273 302 334 395 362 370 245 258 286 321 342 345 323
06400350 378 417 456 532 597 589 568 354 389 424 455 446 458 452
06400420 469 515 561 589 580 571 568 413 455 450 445 437 452 446
06400470 616 604 601 582 583 581 567 462 457 449 445 437 452 446
575 V
05500030 82 92 102 121 142 183 223 73 82 91 108 126 162 198
05500040 120 135 150 180 209 269 328 84 94 104 124 145 187 228
05500069 173 194 215 260 302 388 474 136 153 170 204 236 304 371
06500100 191 215 239 287 334 430 525 166 187 208 249 291 374 457
06500150 253 284 315 376 438 563 515 236 265 294 351 410 466 449
06500190 325 362 399 482 569 500 519 284 317 350 418 496 455 449
06500230 391 448 505 596 612 613 652 343 382 421 478 497 583 582
06500290 534 623 712 737 737 747 749 456 533 573 581 603 583 587
06500350 675 774 763 734 742 748 750 550 501 573 568 595 576 571
Frame size Power loss
5 100 W
6 100 W
