Unidrive M/HS Frame 5 to 6 Power Installation Guide 97
Issue Number: 9
Safety information Product information Mechanical installation Electrical installation
Technical data
UL listing information
Table 5-21 Cable ratings (200 V)
Table 5-22 Cable ratings (400 V)
Table 5-23 Cable ratings (575 V)
The nominal cable sizes below are only a guide. The mounting and grouping of cables
affects their current-carrying capacity, in some cases smaller cables may be acceptable
but in other cases a larger cable is required to avoid excessive temperature or voltage
drop. Refer to local wiring regulations for the correct size of cables.
CAUTION
Model
Cable size (IEC)
mm
2
Cable size (UL)
AWG
Input Output Input Output
Nominal Max
Install
method
Nominal Max
Install
method
Nominal Max Nominal Max
05200250
10 10 B2 10 10 B2 8 8 8 8
06200330
16
25 B2
16
25 B2
4
3
4
3
06200440
25 25 3 3
Model
Cable size (IEC)
mm
2
Cable size (UL)
AWG
Input Output Input
Output
Nominal Max
Install
method
Nominal Max
Install
method
Nominal Max Nominal Max
05400270
6 6 B2 6 6 B2 888 8
05400300
06400350
10
25 B2
10
25 B2
6
3
6
306400420 16 16 44
06400470
25 25 33
Model
Cable size (IEC)
mm
2
Cable size (UL)
AWG
Input Output Input Output
Nominal Max
Install
method
Nominal Max
Install
method
Nominal Max Nominal Max
05500030
0.75
1.5 B2
0.75
1.5 B2
16
16
16
1605500040 11 14 14
05500069
1.5 1.5 14 14
06500100
2.5
25 B2
2.5
25 B2
14
3
14
3
06500150
4 41010
06500190
6 61010
06500230
10
10
88
06500290 6 6
06500350
16 66
