96 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Table 5-6 Maximum permissible continuous output current @ 50 °C (122 °F)
Model
Normal Duty Heavy Duty
Maximum permissible continuous output
current (A) for the following
switching frequencies
Maximum permissible continuous output
current (A) for the following
switching frequencies
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
07200610 75 59.7 48.8 61 53.1 43.2
07200750 94 92.1 80 59.7 48.9 75 69.8 53.1 43.2
07200830 117 112 92.4 80 59.7 49.1 83 81.3 69.7 53.1 43.2
08201160 149 147 133 113 84 116 104 95.1 81.8 72
08201320 180 167 148 133 113 84 132 125 117 104 95.1 81.8 72
09201760 216 197 168 117 84 176 165 140 100 72
09202190 253 237 221 197 168 117 85 219 210 195 166 140 101 72
10202830 325 320 302 266 241 176 130 283 279 241 207 153 114
10203000 346 320 302 266 241 176 130 300 279 243 207 153 114
400 V
07400660 79 73.5 57.7 49 66 55 45 38 30
07400770 94 86.5 73.3 58.3 49 77 70 57 48 41 34
07401000 112 109 87.4 72.8 58.3 49.3 100 91 80 65 55 44 37
08401340 155 146 123 93 69 134 120 99 85 69 55
08401570 184 180 146 123 93.8 69 157 146 132 110 94.2 73.8 58
09402000 221 213 175 144 97 69 200 180 174 143 119 83 58
09402240 253 237 213 176 144 98 69 213 193 175 143 119 83 58
10402700 320 300 259 217 154 112 270 259 214 182 131 97
10403200 343 321 300 260 217 155 112 307 282 259 214 182 131 99
575 V
07500440 53 46.7 35.8 24.8 19 44 35.2 28.1 19.3 15
07500550 73 65 46.7 35.8 24.8 19 55 48.4 35.2 28.1 19.3 15
08500630 86 76.7 64.5 44.3 31.3 63 61.1 48.5 33.4 24.9
08500860 104 97.2 90.7 76.7 64.8 44.3 31.3 86 80.8 61.1 49 33.4 24.9
09501040 125 114 90 62 48 104 97 77 55 42
09501310 150 114 90 62 48 131 126 97 77 55 42
10501520 200 184 154 114 90 62 48 152 150 126 97 78 55 43
10501900 200 196 134 102 66 48 190 171 124 95 63 46
