11 F600 Step By Step Guide
Figure 6-2 Size 4 power and ground connections
L1 L2
L2L1 L3 U V W
L3
Motor
PE
+DC
-DC
4
1
DC Connections
AC Connections
Additional ground
connection
Ground connection
studs
Supply
ground
Optional ground
connection
Mains
supply
Fuses
Optional
line reactor
Optional
EMC filter
