www.usmotors.com
ID300/302 Integrated Motor Drive | Connections
31
7 DIO1 Digital input or output 1
Default Function
ADI1 and ADI2 reference select
Type
Positivelogicdigitalinputonly(foroutput,with6-7kΩpulldown)
Voltage Range 0 V to +24 V
Sample Rate 4 ms
Operating as an Input (Default)
Absolute Maximum Applied Voltage
Range
-8 V to +30 V relative to 0V
Impedance 6.8kΩ
Input Threshold 10 V ± 0.8 V (IEC 61131-2, Type 1)
Operating as an Output
Nominal maximum Output Current 50 mA
Maximum Output Current 200 mA (total, including +24 Vout)
8 DI2 Digital input 2
9 DI3 Digital input 3
10 DI4 Digital input 4
DI2 Default Function
- ID300: Drive enable
- ID302: Not assigned
± 3%
DI3 Default Function
Run forward
DI4 Default Function
Run reverse
Type Positive logic digital input only
Voltage Range 0 V to +24 V
Absolute Maximum Applied Voltage
Range
-18 V To +30 V Relative To 0 V
Impedance 6.8kΩ
Input Threshold 10 V ± 0.8 V (IEC 61131-2)
Sample Rate
1 ms when routed to destinations Pr 06.035 or
Pr 06.036, otherwise 4 ms
Operating as Digital Input (Default)
