Parts of the Camera
The Camera Body
* In this manual, pressing up, down, left, or right on the multi selector is expressed as H, I,
J, or K.
7
10
11
12
12345 6
1314151617
18
19
20
21
22
8
9
1
Eye sensor .......................................................26
2
Electronic viewfinder................................26
3
Diopter adjustment control................. 26
4
x (monitor) button ...............................26
5
K (flash pop-up) control ........... 25, 58
6
Power switch/power-on lamp
(charge lamp)........................................ 17, 20
7
Connector cover ................................... 17, 110
8
Micro-USB connector
..................... 17, 110
9
HDMI micro connector (Type D) ....... 110
10
c (playback) button...............................27
11
Rotary multi selector
(multi selector)*................................ 57, 120
12
k (apply selection) button
............... 120
13
l (delete) button ...................................... 28
14
d (menu) button
................................. 120
15
b (e movie-record) button............. 96
16
g (AE-L/AF-L) button..................... 6, 171
17
Monitor
........................................................10 , 19
18
Power connector cover (for optional
AC adapter)
19
Battery-chamber/memory card slot
cover................................................................... 16
20
Lock lever ........................................................ 16
21
Tripod socket
22
Speaker
