VI Basic Operations MICROSCOPE
6 Using the Microscope Control
- 127 -
• Control the lamp
<Microscope control menu 2>
• Change the condenser
• Adjust the diascopic illumination aperture diaphragm
• Adjust the diascopic illumination field diaphragm
• Adjust the episcopic illumination field diaphragm
• Adjust the transmission factor of the ND filter
• Change the analyzer
<Microscope status display/microscopy setup menu> (MIC Info menu)
• Show the name of the objective
• Show the position of the stage in height direction
• Show the magnification of the optical zoom
• Show the name of the filter
• Set up microscopy and show the current microscopy
<Precautions regarding menu display>
Depending on the type of microscope connected to your system, not all items of the microscope
control menus and microscope status display menus can be displayed. The items that can be
displayed on the DS-L1 menu are limited to those for parts whose status can be detected
electrically among the various parts of your microscope. Keep in mind that the items displayed
on the DS-L1 menu do not include those for parts whose status cannot be detected electrically.
Refer to the table below for the relationship between the microscope system and menu display.
1) When the Nikon 80i microscope incorporating DIH-M is connected
Parts Menu displayed
Focus (Z axis) No menu displayed
Intelligent nosepiece Status display menu displayed Nosepiece
Manual nosepiece No menu displayed
Optical zoom Status display menu displayed
Optical path Status display menu displayed
Shutter Control/status display menu displayed
Filter cube Status display menu displayed
Lamp No menu displayed
Universal condenser No menu displayed
Diascopic illumination aperture diaphragm No menu displayed
Diascopic illumination field diaphragm No menu displayed
Episcopic illumination field diaphragm No menu displayed
ND filter No menu displayed
Analyzer No menu displayed
