Nikon DS-U1 - DS Camera Head DS-5 M; DS Cooled Camera Head DS-5 Mc

Chapter 3 Names of Parts and Their Functions
2 DS Camera Head DS-5M / DS Cooled Camera Head DS-5Mc
- 6 -
2
DS Camera Head DS-5M / DS Cooled Camera Head DS-5Mc
C mount cap
Protects the C mount
from dust.
C mount
When takin
g
microphoto
g
raphs, mount
the C mount adapter here before
connecting to the microscope.
When taking other photographs,
attach the C mount lens here.
CAMERA OUT connector
Tripod mount
This mount can be used to mount
the camera head on a tripod, etc.
Top
Bottom
Rear
NOTE: DS-5M and DS-5Mc have the same
body, only the color differs.
DS-5Mc: Black
DS-5M: White
