Chapter 2 Part Names and Microscopy Procedures (With Epi-illumination Attachment Mounted)
2.2 Names of Parts Used to Make Adjustments
26
2.2.2
Left view
2.2.3
Rear view (without accessory device)
Coarse focus
knob
Fine focus knob
Power ON indicator
Preset switch
Condenser focus knob
Condenser
centering
screw
Coarse focus tor
q
ue
adjustment knob
Bri
g
htness control knob
Tool stora
g
e com
p
artment
Power switch
AC inlet
In
p
ut volta
g
e indication
Lam
p
house mountin
g
section
Lam
p
house
connector port
ND4 filter slider
ND16 filter slider
ND8 filter slider
(Provided on
the right side
in certain
products)
Left side the E
p
i-illumination attachment
