Nikon eclipse fn1 User Manual

Chapter 1 Part Name
13
2
2. TE2-PS100W power supply
The bottom of the power supply becomes extremely hot while it is in use. Do not obstruct the
air vents on the sides of the power supply.
A
nalyzer selector lever
Rear side fine focus knob
Rear side coarse focus knob
Stage movement knob
for the Y-axis
Stage movement knob
for the X-axis
Front side fine focus knob
Front side coarse focus knob
Coarse focus torque adjustment ring
Objective
Field diaphragm control
WARNING
Focus adjustment ring for the rear port
Lamp house
Parfocal correction
knob
Brightness
control knob
Power indicator
This lamp is lit when power is on.
Power switch
Push it to the "I" side to turn on.
Push it to the "O" side to turn off.
A
C inlet
Connect the specified power cord
that meets the voltage provided.
Refer to Chapter 7, "Specification"
for the specified power cord.
OUTPUT connector
This connector is used fo
r
the lamp.
It is connected to the lamp
house through the lamp
cable.
Sanwa Electric
SNS-1603-RSFb
Pin 1: Output +
Pin 2: Output -
Pin 3: Not used
