Review of the menus
Menus in the CTS 602 control
The control will have the main menu as starting point, (the menu in the full-drawn frame). From
here it is possible to go through the other menus via pq.
Option for choosing a low ventilation level at a low outside temperature.
Main menu: displays operating status.
Press ESC to return to the main menu.
Operating mode (heat, auto, cool), temperatures, fan speed, type of unit and
software version.
Alarm display and reset.
Alarm log containing the latest 16 alarms.
SHOW
ALARMS
SHOW
AUTO
>2< 19°C
USER
Options: exhaust, inlet, ventilation, OFF. The function selected is activated via a
switch or pressure.
10-09-13
TM .. 12:10
Date and time settings. The time and date must be reset if the system has been
without power for more than 24 hours. Summer and winter time must also be set
manually.
Weekly program can be set to ON or OFF. When the program is active, 1, 2
or 3 is displayed in the main menu.
SELECT
WEEK
PROGRAM
COOLING
Option for choosing a higher ventilation level when the system is
cooling via open bypass valve.
AIR
EXCHANGE
AIR
FILTER
TEMP.
CONTROL
LANGUAGE
ENGLISH
The controls are factory set to activate a filter alarm every 90 days. The alarm
is reset in the VIEW ALARMS menu.
Setting the minimum temperature required in order for the bypass valve to
close. Maximum inlet air temperature can be set for a heating element.
Select the required language
:
English, German, French, Swedish,
Danish, Norwegian or Finnish.
HEATING
The system has a heating surface installed. The heating surface can be
chosen ON/OFF. Frost-protection is still active when OFF is chosen.
SURFACE
DATA
HUMIDITY
Offers the option to set a higher/lower fan speed at a high/low humidity level
CO
2
The menu is only accessible when the unit has CO2-sensors
installed
NIGHT
Setting of the temperature for passive cooling at night
COOLING
Figure 3: Menu headlines
