Technical data for machines with cylindrical brush deck
Description BR 752C
Cylindrical brush size (diameter x length) 145 x 690 mm
Weight without batteries and with empty tanks 180 kg
Maximum weight with batteries, full tanks and operator (75 kg) (GVW) 451 kg
Cylindrical brush motor power 2 x 600 W
Cylindrical brush speed 720 rpm
Cylindrical brush pressure 35 kg
WIRING DIAGRAM
Key
BAT 24 V battery box
BE Flashing light (optional)
BRK Electromagnetic brake
BZ1 Reverse gear warning buzzer/horn
C1 Battery connector
C2 Battery charger main connector
C3 Battery charger sub-connector
C4 Brush deck connector
CH Battery charger (optional)
EB1 Function electronic board
EB2 Display electronic board
EB3 Dashboard instrument electronic board
ES1 Brush electromagnetic switch
EV1 Solenoid valve
F0 Battery fuse
F1 Brush deck fuse
F2 Main electronic board fuse
F3 Signal circuit fuse
F4 Actuator fuse
K1 Ignition switch
M1.1,2 Brush motor
M2 Vacuum system motor
M3 Drive system motor
M4 Detergent pump (optional)
M5 Brush deck actuator motor
M6 Squeegee actuator motor
m0 Squeegee actuator position 0 microswitch
m1 Squeegee actuator position 1 microswitch
m2 Squeegee actuator position 2 microswitch
PR1 Solution/clean water level pressure switch
RV1 Drive pedal potentiometer
SW1 Driver’s seat microswitch
Colour codes
BK Black
BU Blue
BN Brown
GN Green
GY Grey
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow
(*) Versions without on-board battery charger
(**) Only for BR 652 - BR 752
