BEFORE START-UP
WARNING!
At every machine start-up, check that, between the deck (10 and 28) and the machine or between the squeegee
(30) and the machine, there is no foreign material which may prevent the deck and the squeegee from lifting.
This check is necessary because, if the machine has been turned off without lifting the deck and the squeegee,
the deck and the squeegee will lift automatically at next machine start-up.
Cylindrical brush installation/removal (only for BR 652 / BR 752)
According to the kind of cleaning to be performed, the machine can be equipped either with brushes (A, Fig. 1) or pad-holders (B)
with pads (C) together with the appropriate deck.
For the installation/removal, proceed as follows.
1. Insert the ignition key (58) and turn it to “I”.
WARNING!
Before pressing the switch (67), always check that, between the deck (10) and the machine there is no foreign
material which may prevent the deck from lifting.
2. Lift the deck by pressing the switch (67).
3. Turn the ignition key (58) to “0” and remove it.
4. Install the brushes/pad-holders (A or B) in the drive hub (D) under the deck, then turn them in the opposite direction to their
rotation direction, until they reach the end of stroke (E).
5. To remove the brushes/pad-holders perform steps 1 to 3, then manually release the brush/pad-holder from the hub by turning
it abruptly in its normal rotation direction (F).
WARNING!
If the machine is not perfectly assembled it can cause damages to people and properties. Always check that all
components are assembled before starting the machine. Carefully inspect the machine before using it.
