4 - FORM NO. 56043093 / Captor
™
4300, 4800, 5400
SPECIFICATIONS
GeneralSpecicationscommontoAll Models English (Metric)
Dimensions Gas & Propane
Length 105 inches (267cm)
Height 58 inches (147cm)
Height w/overhead guard 79 inches (200cm)
Ground clearance 3 inches (7.6cm)
Minimum ceiling height dumping clearance 92 inches (233.6cm)
Weights
Net weight* 4040 lbs. (1832kg)
Gross weight** 4720 lbs. (2141kg)
Speed and Gradeability
Maximum travel speed 6 mph (9.6km/h)
Maximum reverse speed 4 mph (6.4km/h)
Maximum grade angle scrubbing 6 deg.
Maximum grade angle non-scrubbing 8 deg.
Sound Level
At operators ear 85.1 dBA
Sweep System
Sweeping path w/out side broom(s) 40 inches (102cm)
Main broom length 40 inches (102cm)
Main broom diameter 14 inches (35.5cm)
Side broom diameter 20 inches (50.8cm)
Side broom bristle length 7 inches (17.7cm)
Hopper System
Capacity 9.2 Cu. Ft. (261 L)
Lifting capacity 550 lbs. (250kg)
Dump height (variable) Max. 60 inches (152cm)
Dump height with door open 56-1/2 inches (143.5cm)
Dust Control System
Filter type: Pleated paper panel
Filter dimension 3-3/16” x 20” x 27” (8cm x 50.8cm x 68.5cm)
Filter media area 78 ft
2
(7.25m
2
)
Steering System
Type: Power steering unit with rack and pinion
Turns lock to lock right: 4-3/8
Turns lock to lock left: 3-3/8
Minimum aisle turn width 118 in. (300cm) left and right
Hydraulic System
Oil type: SAE 10W-30
System ll capacity 11 gal. (41.6 L)
Engine System
Engine coolant ll capacity 10-11 qts. (9.5-10.4L)
Recovery System
Vacuum water lift (sealed) minimum 22 inches
Vacuum water lift (open hole adapter 1”) minimum 20 inches
*Net Weight: Standard machine without options, empty solution and recovery tanks, without removable scrub brushes and full tank of fuel.
**Gross Weight: Standard machine without options, full solution tank and empty recovery tank, with removable scrub brushes and full tank of
fuel.
