General Information
9
Service Manual – SC100 - Scrubtec 130
Technical Data
Model SC100 - Scrubtec 130
Solution tank capacity 3 liters
Recovery tank capacity 4 liters
Machine size (length x width x height) 400 x 360 x 1,150 mm
Cleaning width 310 mm
Brush diameter 66 mm
Min/max solution ow 0.2 / 0.6 L/min
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 72 dB(A) ± 2 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 83 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Maximum gradient when working 2 %
IP protection class X4
Protection class (electric) II
Vacuum system capacity 360 mm H
2
O
Brush rotation speed 2,100 rpm
Total absorbed power 0.8 kW
Electrical system voltage 220-240 V - 50-60 Hz
Weight with empty tanks 12 kg
Gross vehicle weight (GVW) 15 kg
Shipping weight 16 kg
Maintenance
The lifespan of the machine and its maximum operating safety are ensured by correct and regular maintenance.
The following chart provides the scheduled maintenance. The intervals shown may vary according to particular
working conditions.
Warning! Maintenance procedures must be performed with the machine switched off and the
powersupplycableplugdisconnectedfromtheelectricalmains.Moreover,carefully
readtheinstructionsintheSafetychapter.
Scheduled Maintenance Table
Procedure
Daily, after using the
machine
Weekly Every six months
Squeegee bar cleaning
Brush Cleaning
Recovery Tank Cleaning
Brush compartment and inspection compartment cleaning
Power supply cable check
Dosing bridge cleaning
Squeegee bar check
Detergent lter cleaning
Air lter cleaning
Solution tank cleaning
Squeegee bar replacement
