Scrubtec 130 Nomenclature
1. Handle
2. Start/stop switch
3. Solution switch
4. Power supply cable with connector
5. Serial number plate/technical data/conformity
certication
6. Stop position unlocking pedal
7. Squeegee bar lifting/lowering pedal
8. Tank coupling and transport handle
9. Solution tank
10. Solution tank ller plug
11. Solution lter
12. Recovery tank
13. Cleaning deck
14. Brush engagement/disengagement lever
15. Brush
16. Squeegee bars
17. Inspection lid
18. Recovery water vacuum hose
19. Air lter cover
20. Recovery tank drain plug
21. Vacuum inlet plug
22. Brush/vacuum motor compartment
23. Rear wheels
24. Transport handle housing
25. Power supply cable holder
