Service Manual – SC100 - Scrubtec 130
SC100 Nomenclature
1. Handle
2. Main switch
3. Start/stop switch
4. Solution switch, level 1
5. Solution switch, level 2
6. Empty solution tank warning LED
7. Stop position unlocking pedal
8. Squeegee bar lifting/lowering pedal
9. Tank coupling and transport handle
10. Solution tank
11. Solution tank ller plug
12. Solution lter
13. Recovery tank
14. Cleaning deck
15. Brush engagement/disengagement lever
16. Brush
17. Squeegee bars
18. Inspection lid
19. Recovery water vacuum hose
20. Air lter cover
21. Recovery tank drain plug
22. Vacuum inlet plug
23. Brush/vacuum motor compartment
24. Rear wheels
25. Transport handle housing
26. Power supply cable holder
27. Power supply cable with connector
28. Serial number plate/technical data/conformity
certication
1
9
13
14
18
34
5
6
1617
12
10
20
11
25
27
2
158
7
28
21
22
19 2324
26
