Cylindrical Brush System 38Service Manual – SC100 - Scrubtec 130
Belt and Pulley Disassembly/Assembly (Continues)
9. With a screwdriver slightly separate the trigger lever (E) from the track (F), then lift the front side (G)
of the cover (H) as shown in the gure.
10. Remove the cover (H) by disengaging its ends (I) from the machine.
F
H
E
G
I
I
H
