Nilfisk-ALTO SC100 User Manual

Cylindrical Brush System 40Service Manual – SC100 - Scrubtec 130
Belt and Pulley Disassembly/Assembly (Continues)
15. To remove the belt (T), on the motor side, perform the following procedures:
◦ Remove the belt (T) from the ring gear (U),with a screwdriver, then retrieve it.
Assembly
16. Assemble the components in the reverse order of disassembly.
U
T
