Nilfisk-ALTO SCRUBTEC R 571 - Parts List

Nilfisk ALTO Operator's Manual -
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual Steering Page -35-
Nilfisk ALTO
SCRUBTEC R 571, 586SCRUBTEC R 571, 586
SCRUBTEC R 571, 586SCRUBTEC R 571, 586
SCRUBTEC R 571, 586
Main Frame Assembly Parts List (Rotary) 3/08
Drawing #11098A
Ref Part No. Description Qty
1 53386B Actuator, Head Lift 1
1A 40910A Potentiometer & Circuit Borad 1
1B 40866A Housing Potentiometer 1
2 766780 Pin, Hair 1
3 82501A Pin, Clevis 1
4 40889A Horn 1
5 962288 Bolt, 3/8-16 x 1 Hex Hd 8
6 170883 Washer, Lock 3/8” 22
7 980645 Washer, 3/8” S.A.E. Flat 22
8 53760A Steering Asm. , Manual 1
9 61473A Linkage, Rod 4
10 920204 Nut, 3/8-24 Hex Jam 8
11 53493A Pin, Quick Release Act. Btm. 1
12 61482A Weldment, Head Carriage 1
13 818381 Spring, Idler Tension 1
14 61475A Clamp, Transaxle 2
15 51609A Bumper, Rear 2
16 962929 Screw, 10-32 x 3/8” 2
17 81221A Nut, 1/2-20 Lug 8
18 61382A Wheel, Anti-Skid 2
19 40837A Transaxle 1
19A 40798A Brake 1
19B 41020A Motor 1
20 61572A Mount, Front Squeegee 1
21 962086 Screw, 1/4-20 x 3/4 Hex Hd. 2
22 980657 Washer, Lock 1/4 6
23 962244 Bolt, 3/8-16 x .75 Hex 6
24 85813A Screw, 5/16-18 x 1 Hex Hd. 2
25 980652 Washer, 5/16 Lock 2
26 61491A Bracket, Squeegee Stop 1
27 61481A Weldment, Mainframe 1
28 30453A Hose, Clear Vinyl 1
29 61596A Stop, Brush Head 1
30 30558A Pad, Brush Carriage Stop 1
31 87026A Washer, 1/4 Flat SS 2
32 85737A Screw, 1/4-20 x 1/2 HHCS 6
33 50248A Clamp, Hose 1
34 59614A Valve, Battery Drain 1
35 722030 Clamp, Hose 2
36 30445A Hose, Solution (Flex) 1
37 48703A Valve, Electric 1
38 81104A Nut, 1/4” Nylock 3
39 69639A Strap, Static 1
40 85700A Screw, 1/4-20 x 1 HHCS 1
41 980614 Washer, 1/4” Starlock Ext. 3
42 980205 Washer, .31 I.D. x 1.06 O.D. 2
NOTE:  indicates a
change has been made
since the last publica-
tion of this manual.
