Nilfisk-ALTO SCRUBTEC R 571 - Parts List

Nilfisk ALTO Operator's Manual -
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual SteeringSCRUBTEC R Manual Steering
SCRUBTEC R Manual Steering Page -41-
Nilfisk ALTO
SCRUBTEC R 571, 586SCRUBTEC R 571, 586
SCRUBTEC R 571, 586SCRUBTEC R 571, 586
SCRUBTEC R 571, 586
Optional Side Squeegee Lift Assembly Parts List 5/05
Ref Part No. Description Qty
1 87624A Washer, Nylon 1 1/2 x 1/4 x 1/8 2
2 86004A Screw, 1/4-20 x 1.50 HHCS 1
3 920296 Nut, 10-24 Elastic Stop 1
4 61699A Bracket, Sq. Lift Cable 1
5 962798 Screw, 10-24 x 1/2 PH 1
6 836711 Pin, Hair 2
7 80152A Washer, Flat 5/8 1
8 920110 Nut, 5/16-18 Hex Lock 1
9 980651 Washer, 5/16 Flat 1
10 80286A Spring, Actuator 1
11 80287A Screw, 5/16-18 x 7 Hex Head 1
12 80273A Pin, Clevis 2
13 61698A Bracket, Actuator Rear Mount 1
14 40751A Actuator, 3” Stroke 1
15 81104A Nut, 1/4” Nylock 1
16 61695A Cable, Squeegee Lift 1
17 57275A Pulley, Cable 1
