SCRUBTEC R Manual Steering Page -37-
Nilfisk ALTO
SCRUBTEC R 571CSCRUBTEC R 571C
SCRUBTEC R 571CSCRUBTEC R 571C
SCRUBTEC R 571C
Main Frame Assembly Parts List 3/08
Drawing #10949S
Ref Part No. Description Qty
1 766780 Pin, Hair 1
2 82501A Pin, Clevis 1
3 40771A Actuator, Head Lift 1
3A 40910A Potentiometer & Circuit Borad 1
3B 40866A Housing Potentiometer 1
4 40889A Horn 1
5 962288 Bolt, 3/8-16 x 1 Hex Hd. 3
6 53760A Steering Asm, Manual 1
7 61736A Bracket, Head Stop (Cyl.) 1
8 980657 Washer, Lock 1/4 2
9 85737A Screw, 1/4-20 x 1.2 HHCS 4
10 920204 Nut, 3/8-24 Hex Jam 4
11 170883 Washer, Lock 3/8” 17
12 980645 Washer, 3/8” SAE Flat 17
13 61473A Linkage, Rod 4
14 53493A Pin, Quick Release Actuator Btm. 1
15 61718A Carriage, Weldment 1
16 962244 Bolt, 3/8-16 x .75 Hex 10
17 61475A Clamp, Transaxle 2
18 51609A Bumper, Rear 2
19 962929 Screw, 10-32 x 3/8” 2
20 81221A Nut, 1/2-20 Lug 8
21 61382A Wheel, Anti-Skid 2
22 40837A Transaxle 1
22A 40798A Brake 1
22B 41020A Motor 1
23 85813A Screw, 5/16-18 x 1 Hex Hd. 2
24 980652 Washer, 5/16 Lock 2
25 61836A Bracket, Squeegee Stop 1
26 61719A Frame, Main Weldment 1
27 30453A Hose, Clear Vinyl 1
28 50248A Clamp, Hose 1
29 59614A Valve, Battery Drain 1
30 48703A Valve, Electric 1
31 81104A Nut, 1/4” Nylock 3
32 69639A Strap, Static 1
33 980205 Washer, .31 I.D. X 1.06 O.D. 2
34 980614 Washer, 1/4” Starlock, Ext. 3
35 85700A Screw, 1/4-20 x 1 HHCS 1
36 413754 Grip, Solution Tank Clamp 1
NOTE:  indicates a change has been made since the last
publication of this manual.
