Recovery Tank Assembly Parts List 6/07
Drawing # 10783A & 10990A
Ref Part No. Description Qty
1 52206A Chain, Drain Asm. 1
2 962957 Screw, 10 -16 x 1/2 Self Tab 2
3 30227A Housing, Drain 1
4 40002A Switch, Float Electrical 1
5 30622A Hose, Vac Exhaust 1
6 752020 Clamp, Hose 1
7 58069A Screen, Vac Filter 1
8 30581A Lid, Recovery Tank 1
9 30582A Gasket, Rec. Tank Lid 1
10 39339B Tube, Stand 90
o
1
11 837304 O-Ring, Retainer 2
12 82100A Locknut, 1/02 1
13 30709A Tank, Recovery (571 model) 1
13 30710A Tank, Recovery (586 model) 1
13 30711A Tank, Recovery (571 C model) 1
14 920797 Nut, Drain Valve 1
15 30623A Tube, Stand Straight 1
16 643418 Gasket, Vac Unit 1
17 58533A Spacer, Vac Motor 3
18 45019A Motor, Vac` 1
18A 40830A Carbon Brush 2
19 41809A Contact, Housing Connector 2
20 43401A Housing, Connector 2
21 85728A Screw, 1/4 - 20 x 4 Hex HD 3
22 61565A Panel, Recovery Vac Motor 1
23* 962212 Screw, 6-32 x 7/8 PH 2
24* 40874A Light, Strobe 1
25* 61579A Bracket, Strobe Light 1
26 85395A Screw, 1/4 - 20 x 1/2 PH 8
27* 84237A Screw, 10-32 x .50 PH 4
28 920056 Nut, 6-32 ESNA Nylock 2
29 77093A Label 1
30* 920722 Nut, 10-32 ESNA 4
31 61478A Retainer, Lower Hose 1
32 30561A Coupler, Hose (Rotary Machine) 1
682408 Connector, Hose (Cyl. & BOOST) 1
33 61573A Cable, Recovery Tank 1
34 61498A Retainer, Mid Hose 1
35 61477A Retainer, Upper Hose 1
36* 30559A Gasket, Clean Out 1
37* 61566A Clean-Out, Drain 1
38* 52477A Knob, 1/4 - 20 Clamp 4
39 30443A Hose, Recovery 1
40 832002 Clamp, Hose 2
41 30225A Body, Drain Valve 1
42* 40876A Sensor, Water Level 1
43 52560A O-Ring, .103 x 7.99 ID 1
44 30226A Plug, Drain 1
NI 30568A Hose, Squeegee 1
NI 30567A Hose, Vac 1
NOTE: * Optional accessories
NI = Not illustrated
