Nokia 7210 SAS-M User Manual

Getting Started
20
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
For 7210 SAS platforms that support multiple explicit modes of operation (Table 1),
the operating mode must be configured in the Boot Option File (BOF) to ensure the
router boots up in the specified mode. For example, the 7210 SAS-M supports
access-uplink and network modes of operation, and the 7210 SAS-Sx/S 1/10GE
supports satellite, standalone, and standalone-VC mode of operations. In some
cases, the 7210 SAS router operates in a specific mode implicitly, and explicit
configuration is not required.
Refer to the appropriate Basic System Configuration Guide for boot options and
information about how to boot the 7210 SAS platform in a specific operating mode.
Table 1 lists the supported modes of operation and the configuration methods for the
7210 SAS platforms. Unless explicitly noted otherwise, the operating mode is
supported on all variants of the specific 7210 SAS platform.
Table 1 Supported Modes of Operation and Configuration Methods
7210 SAS Platform Mode of Operation and Configuration Method
Network Access-Uplink Standalone Standalone-VC Satellite
7210 SAS-D Implicit Implicit
7210 SAS-Dxp Implicit Implicit
7210 SAS-K 2F1C2T Implicit Implicit
7210 SAS-K 2F6C4T
2
Port Mode
4
Configuration
Port Mode
4
Configuration
Implicit
7210 SAS-K 3SFP+ 8C
2
Port Mode
4
Configuration
Port Mode
4
Configuration
Implicit
7210 SAS-M Explicit BOF
Configuration
Explicit BOF
Configuration
Implicit
7210 SAS-Mxp
Implicit
3
Explicit BOF
Configuration
Explicit BOF
Configuration
7210 SAS-R6
1
Implicit Implicit
7210 SAS-R12
1
Implicit Implicit
7210 SAS-Sx/S 1/10GE
Implicit
3
Explicit BOF
Configuration
Explicit BOF
Configuration
Explicit BOF
Configuration
7210 SAS-Sx 10/100GE
Implicit
3
Explicit BOF
Configuration
Explicit BOF
Configuration
Explicit BOF
Configuration
7210 SAS-T Explicit BOF
Configuration
Explicit BOF
Configuration
Implicit
