Getting Started
22
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Table 2 lists the port mode configuration support per 7210 SAS mode of operation.
Note:
1. Port modes are configured on the 7750 SR host and managed by the host.
Table 3 lists the port mode configuration supported by the 7210 SAS product family.
Refer to the appropriate Interface Configuration Guide for detailed information about
configuring the port modes for a specific platform.
Note: The 7210 SAS-K 2F6C4T and 7210 SAS-K 3SFP+ 8C are unique; all port modes
listed in Table 2 are available for configuration on the router, regardless of the current mode
of operation.
Table 2 Supported Port Modes by Mode of Operation
Mode of Operation Supported Port Mode
Access Network Hybrid Access-
uplink
Access-Uplink ✓ ✓
Network ✓✓✓
Satellite
1
Standalone ✓✓✓
Standalone-VC ✓✓✓
Table 3 7210 SAS Platforms Supporting Port Modes
Platform Port Mode
Access Network Hybrid Access-
uplink
7210 SAS-D Yes No No Yes
7210 SAS-Dxp Yes No No Yes
7210 SAS-K 2F1C2T Yes No No Yes
7210 SAS-K 2F6C4T Yes Yes Yes Yes
7210 SAS-K 3SFP+ 8C Yes Yes Yes Yes
7210 SAS-M Yes
Yes
1
Yes
2
Yes
3
