Nokia 7210 SAS-M User Manual

System Management
404
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
The 7210 SAS validates the configured card-types with the card-type acronym retrieved from
the clip-on device and checks the following.
• If the configured card-type matches the card type acronym retrieved from the clip-on
device, the 7210 SAS allows management of the module.
• If the configured card-type does not match the card type acronym retrieved from the clip-
on device, the 7210 SAS raises an event to alert the user of mismatch in configuration.
The event results in a major alarm with the major LED set. In such a case, the card status
displays “Provisioning Mismatch” error.
• The mismatch event/trap is cleared if the module is replaced with the one that has a
correct card type acronym. Any pending trap/event, major alarm and major LED is
cleared.
If the user set the card to administratively up and the module is missing, the 7210 SAS raises
an event/trap. The event results in a major alarm with the major LED set to the appropriate
color. If the user has preprovisioned the card and administratively shut it down, the software
does not attempt to match the module’s identifier (if the module is equipped in the slot) and
clears any pending alarms. The software retrieves any information about the equipped
module to aid the user with provisioning.
The no form of this command removes and clears the card-type information. Until the card-
type is provisioned, the software does not raise any events/traps/alarms for the card and
clears all pending events/traps/alarms/LEDs.
Table 42 lists the acronyms defined by the optical group. For more information, see the
Product overview guide for 1830 VWM. This is used to preprovision the acceptable modules
that can be equipped in the slots of the clip-on device.
Table 42 Card Type Acronyms for 1830 CWDM Devices
Module Description Acronym
1830 VWM 1-CH CWDM FILTER (AB VARIANT) - CH1 (1471nm) SFC1A
1830 VWM 1-CH CWDM FILTER (AC VARIANT) - CH1 (1491nm) SFC1B
1830 VWM 1-CH CWDM FILTER (AD VARIANT) - CH1 (1511nm) SFC1C
1830 VWM 1-CH CWDM FILTER (AE VARIANT) - CH1 (1531nm) SFC1D
1830 VWM 1-CH CWDM FILTER (AF VARIANT) - CH1 (1551nm) SFC1E
1830 VWM 1-CH CWDM FILTER (AG VARIANT) - CH1 (1571nm) SFC1F
1830 VWM 1-CH CWDM FILTER (AH VARIANT) - CH1 (1591nm) SFC1G
1830 VWM 1-CH CWDM FILTER (AI VARIANT) - CH1 (1611nm) SFC1H
1830 VWM 2-CH CWDM FILTER (AK VARIANT) - CH1,2 SFC2A&B
1830 VWM 2-CH CWDM FILTER (AL VARIANT) – CH3,4 SFC2C&D
