System Management
532
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
7210 SAS-R6 and
7210 SAS-R12
On the 7210 SAS-R6 and 7210 SAS-R12, the features that
share the resource pool are different based on the IMM card
type.
On IMMv1, IMMv2, and IMM-c cards
1
, this resource pool is
shared among the following features:
• SAP ingress QoS classification (all of IPv4, IPv6, and MAC
match-criteria)
• ingress ACLs (all of IPv4, IPv6, and MAC match-criteria)
• Ethernet CFM MEP (Up and Down)
• SAP ingress aggregate meter
• network port and IP interface ingress QoS classification
• SAP egress based queuing and scheduling (not applicable
to IMM-c cards)
•CPU protection
• MAC authentication (7210 SAS-R6 only)
• access port ingress QoS policies
7210 SAS-Sx 1/10GE
(standalone)
• SAP ingress QoS classification (IPv4 and IPv6 match-
criteria)
• Ingress ACLs (all of IPv4, IPv6, and MAC match-criteria)
• Ethernet CFM Up MEP, Down MEP
• SAP ingress aggregate meter
• MAC authentication
7210 SAS-Sx 1/10GE
(standalone-VC)
• SAP ingress QoS classification (IPv4 and IPv6 match-
criteria)
• Ingress ACLs (all of IPv4, IPv6, and MAC match-criteria)
• Ethernet CFM Up MEP, SAP Down MEP, SDP Down MEP,
ingress MIP
• SAP ingress aggregate meter
• MAC authentication
7210 SAS-S 1/10GE
(standalone)
• SAP ingress QoS classification (IPv4 and IPv6 match-
criteria)
• Ingress ACLs (all of IPv4, IPv6, and MAC match-criteria)
• Ethernet CFM Up MEP, Down MEP
• SAP ingress aggregate meter
• MAC authentication
Table 49 Ingress Internal TCAM Resource Sharing (Platforms and
Features) (Continued)
Platform Features Sharing Ingress Internal TCAM Resource Pool
