Nokia 7210 SAS-M User Manual

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 535
Note:
1. The maximum value is 9 if qos-network-ingress-resource is configured as 0.
ipv4-ipv6-128-match-enable
Syntax [no] ipv4-ipv6-128-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>acl-sap-ingress
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by ingress filter policies using ipv6
criteria with 128-bit IPv6 addresses.
The resources can be shared with IPv4 ingress filter policies. Refer to the 7210 SAS-M, T,
R6, R12, Mxp, Sx, S Router Configuration Guide for more information on how to allow filter
policies using IPv4 criteria to share resources with filter policies that use IPv6 criteria with
128-bit address and resource allocation and fields available for use.
The no form of this command specifies that the software does not allocate any resources for
use by ingress filter policies using ipv6 criteria with 128-bit IPv6 addresses. If no resources
are allocated for use, the software fails all attempts to associate a service entity (for example,
SAP and IP interface) with an ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
Some platforms include the value max. If the user specifies max, the software
allocates one chunk when the first SAP is associated with an ingress filter policy
using this match criteria. It continues to allocate resources to the service entity
associated with an ingress filter policy using this criteria, as long as the total amount
of resources allocated does not exceed the resources allocated to ingress filter
policies (configured with the config system resource-profile ingress-internal-
tcam acl-sap-ingress command) and chunks are available for use.
Values Table 51 lists the parameter values.
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 2
7210 SAS-S 1/10GE (per node)
(standalone)
063
7210 SAS-S 1/10GE (standalone-VC) 0 5 2
7210 SAS-Sx 10/100GE (per node) 0 4 1
Table 50 Number of Resources Available for ACL-SAP-Ingress
Platforms Min value
(per node)
Max value
(per node)
Default
Values
