System Management
540
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
ipv4-match-enable
Syntax ipv4-match-enable num-resources
no ipv4-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>qos-sap-ingress-resource
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by SAP ingress QoS policies using IPv4
criteria (any).
The resource cannot be shared with SAP ingress QoS filter policies using mac criteria or ipv6
criteria. Refer to the 7210 SAS-M, T, Mxp, Sx, S Quality of Service Guide for more
information on resource allocation and fields available for use.
The no form of this command specifies that the software does not allocate any resources for
use by SAP ingress QoS policies using ipv4 criteria. If no resources are allocated for use, the
software fails all attempts to associate a service entity (for example, SAP and IP interface)
with a SAP ingress QoS policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
7210 SAS-R6 and 7210 SAS-R12 (per IMM-c) 0 9 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node) (standalone) 0 6 max
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 max
7210 SAS-S 1/10GE (per node) (standalone) 0 6 max
7210 SAS-S 1/10GE (standalone-VC) 0 5 max
7210 SAS-Sx 10/100GE (per node) 0 4 max
Table 53 Number of Resources Available for IPv4-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
