System Management
560
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Description This command configures the queuing mode to be used for SAPs configured on all the ports
of the node.
When port-scheduler-mode is enabled, software allocates 8 egress queues per port and all
the SAPs configured on the access port or hybrid port will share the 8 egress queues for traffic
sent out of that port. In this mode, SAPs configured on hybrid port shares the egress queues
with network port traffic. Enabling port-scheduler-mode affects the behavior for all the SAPs
configured on all the access and hybrid port. In this mode, per SAP egress queues are not
available.
In this mode, resources allocated towards SAP egress queues in the ingress-internal-tcam
pool are not required by this feature and can be allocated towards other features. See the
qos-sap-egress-resource command for more information.
The no form of this command disables port-scheduler-mode, causing per SAP egress
queues to be available for use. Refer to the 7210 SAS-M, T, Mxp, Sx, S Quality of Service
Guide for more information on the two modes.
Enabling or disabling port-scheduler-mode requires a reboot of the node.
Default no port-scheduler-mode
router
Syntax router
Context configure>system>resource-profile
configure>system>global-res-profile
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document
Description
This command enables the context to configure router parameters that is applicable to the
entire chassis (in other words it applies to all IMMs).
ecmp
Syntax ecmp max-routes-dest
no ecmp
Note: The configure>system>resource-profile context is supported on the 7210 SAS-M,
7210 SAS-T, 7210 SAS-Mxp, 7210 SAS-Sx/S 1/10GE: standalone, and 7210 SAS-Sx 10/
100GE.
The configure>system>global-res-profile context is supported on the 7210 SAS-R6,
7210 SAS-R12, and 7210 SAS-Sx/S 1/10GE: standalone-VC.
