Nokia 7210 SAS-M - Page 611

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 611
IPv6-64 bit Resource Displays the resources configured for use by ingress ACL
policies that use ipv6 64-bit address match-criteria
Disable — No resources are allocated for use by this
feature. Therefor, no policies of this type can be associated
to a SAP.
Eth CFM Groups the context for resources consumed by Ethernet
CFM applications
up-mep Displays the resources configured for use by UP MEP
Disable — No resources are allocated for use by this
feature. Therefore, no UP MEPs can be created.
Sap Ingress QoS
resource
The total amount of ingress internal CAM chunks configured
for use by SAP ingress classification
Mac and IPv4
Resource
The total amount of egress internal CAM chunks configured
for use by MAC and IPv4 egress ACL match criteria policies
Mac-only Resource The total amount of egress internal CAM chunks configured
for use only by MAC egress ACL match criteria policies
IPv6 128 bit
Resource
The total amount of egress internal CAM chunks configured
for use only by IPv6 egress ACL match criteria policies
(128-bit IPv6 address can be specified in the match criteria)
Mac and IPv6 64 bit
Resource
The total amount of egress internal CAM chunks configured
for use by MAC and IPv6 egress ACL match criteria policies
(only 64-bit higher order bits of the IPv6 address can be
specified in the match criteria)
system-max-ecmp Displays the maximum number of routes that will be
allocated per IP destination/prefix in hardware when the
user enables ECMP path sharing using multiple routes
Sap Egress ACL
resource
Displays the egress ACL resource allocation configured for
various match criteria
Egress Internal CAM Displays the resource allocation configured for the egress
internal CAM
IPv6 FIB Displays the amount of IPv6 FIB size configured for use by
IPv6 routing
G8032-fast-flood Displays the resources configured for use by G8032 fast-
flood feature
Disable — No resources are allocated for use by this feature
Table 74 Output Fields: System Resource Profile (Continued)
Label Description
