Nokia 7210 SAS-M User Manual

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 621
peers
Syntax peers [router router-instance | service-name service-name] [detail]
Context show>system>ptp
Supported
Platforms
7210 SAS-M (network and access-uplink), 7210 SAS-Mxp, 7210 SAS-R6, 7210 SAS-R12,
7210 SAS-Sx 10/100GE, 7210 SAS-T (network and access-uplink)
Description This command displays summary information for all the PTP peers.
Parameters router-instance — Displays only the information for a specific router instance.
Values router-name: Base
vprn-svc-id: 1 to 2147483647
service-name — Specifies the service name to identify the router instance, up to 64
characters.
detail — Displays detailed information.
Output The following output is an example of PTP information for all peers, and Table 77 describes
the output fields.
Sample Output
*A:bksim1618# show system ptp peers
===============================================================================
IEEE 1588/PTP Peer Information
===============================================================================
Router
Clock ID Displays the clock identity value of the local PTP clock
GM Clock Class Displays the grand master clock class
GM Clock Accuracy Displays the grand master clock accuracy designation
GM Clock Variance Displays the grand master clock variance
GM Clock Priority1 Displays the grand master clock priority1 designation
GM Clock Priority2 Displays the grand master clock priority2 designation
Steps Removed Displays the number of hops from GM
Parent Clock yes — if the peer is the chosen parent clock
no — if the peer is not the chosen parent clock
Table 76 Output Fields: PTP Peer (Continued)
Label Description
