7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT

Issue: 01 3FE-48009-AAAA-TCZZA 101

2 Configure a WAN DHCP option.

3 Click Save.

4 STOP. This procedure is complete.

Procedure 19 WiFi 2.4G networking configuration

1 Select Network > WiFi 2.4G from the top-level menu in the GPON Home Gateway window,

as shown in Figure 35.

Figure 35 WiFi 2.4G network window
