7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
Issue: 01 3FE-48009-AAAA-TCZZA 115
Figure 43 QoS Config window (L3)
Table 35 describes the fields in the QoS Config window.
Table 35 QoS Config parameters
Field
Description
Type
Choose a QoS service layer type from the drop-down menu L2 or L3.
Source MAC
Enter the source MAC
Select the Exclude checkbox to exclude the source MAC
Interface
Choose an interface from the drop-down menu
DSCP Mark
Enter the value for the DSCP mark (range: 0-63); valid only for L3 Criteria
802.1p Mark
Enter the value for the 802.1p (range: 0-7)
