7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
Issue: 01 3FE-48009-AAAA-TCZZA 125
Figure 49 IP filter window
Table 41 describes the fields in the IP filter window. If the firewall level is not set to
advanced, the IP filter rules are not available.
Table 41 IP filter parameters
Field
Description
Mode
Choose an IP filter mode from the drop-down menu:
• Drop for upstream
• Drop for downstream
Internal Client
Choose an internal client from the drop-down menu:
• Customer setting - uses the IP address input below
• IP - uses the connecting devices' IP to the ONT
Local IP Address
Local IP address
Source Subnet Mask
Source subnet mask
Remote IP Address
Remote IP address
Destination Subnet Mask
Destination subnet mask
Protocol
Choose an application protocol or all from the drop-down menu
2 Configure the IP filter.
3 Click Add.
