Configure a G-240W-J indoor ONT 7368 ISAM ONT G-240W-J Product Guide
134 3FE-48009-AAAA-TCZZA Issue: 01
1 Select Application > Port forwarding from the top-level menu in the GPON Home Gateway
window, as shown in Figure 54.
Figure 54 Port forwarding window
Table 46 describes the fields in the port forwarding window.
Table 46 Port forwarding parameters
Field
Description
Application Name
Choose an application name from the drop-down menu
WAN Port
WAN port range
LAN Port
LAN port range
Internal Client
Choose a connected device from the drop-down menu and enter the associated IP
address
Protocol
Choose the port forwarding protocol from the drop-down menu:
• TCP
• UDP
• TCP/UDP
Enable Mapping
Select this checkbox to enable mapping
WAN Connection List
Choose a WAN connection from the drop-down menu
Note: only active devices are shown on this menu
2 Configure port forwarding.
