Installation procedure
58
Nokia FastMile Outdoor Unit User Manual
3TG-00088-AAAA-TCZZA Issue: 01P03
Figure 20 Attaching the mounting plate to the Nokia FastMile Outdoor Unit
iv Use a Phillips screwdriver to remove the cover from the SIM slot of the Nokia FastMile
Outdoor Unit, insert a valid Nano/4FF SIM card in the slot, and re-attach the cover on
the SIM slot. Figure 19 shows the location of the SIM slot on the Nokia FastMile Outdoor
Unit.
v As appropriate, drill a hole through the wall for the Ethernet cable from the Nokia
FastMile Outdoor Unit to be able to pass through. It is recommended that you drill the
hole for the Ethernet cable at a slight angle so that any water that might enter the hole
will run down towards the outside of the home.
vi As appropriate, drill two anchor holes for the wall-mount bracket on the outside of the
wall. The anchor holes should be one directly above the other. You can use the
wall-mount bracket as a template for the anchor holes.
vii Mount the wall-mount bracket on the outside of the wall using two appropriate fasteners
in the anchor holes drilled in the previous step, as shown in Figure 21. Ensure that the
wall-mount bracket is in a vertical position on the wall.
Install the
screws
27899
