Nokia FastMile Outdoor Unit User Manual Installation procedure
Issue: 01P03 3TG-00088-AAAA-TCZZA 69
19 You can view the following information by selecting the Connection Status option of the main
screen:
• General stats:
• bytes sent: the total number of bytes sent on the interface
• bytes received: the total number of bytes received on the interface
• LTE cell stats:
• cell ID: The ECI of cell
• connection state: Does ODU connect to this cell
• status: The current operational state of the PDN connection
• EARFCN: The carrier frequency in the uplink and downlink is designated by the E-UTRA.
Absolute Radio Frequency Channel Number (EARFCN) in the range 0 - 65535.
• PCI: The physical cellid of cell
• RSRP: The average value of Reference Signal Received Power (dBm) in measured
interval, resolution 1dBm.
• RSRQ: The average value of Reference Signal Received Quality (dB) in measured
interval, resolution 1dB.
• RSSI: The average value of Received Signal Strength indicator (dBm) in measured
interval, resolution 1dBm.
• SINR: The average value of Signal-to-Interference-plus-Noise Ratio (dB) in measured
interval, resolution 1dB.
Figure 33 shows an example of the System state screen.
Note — After Fresh Installation and when LTE attach is successful,
some of the values displayed will not be updated for some time (values
will be zero until the first 15minutes interval is finished).
