NORAM 65ET GRADER
4-25
Lubrication and Maintenance - Grader Components
4
Every 250 Hours or Monthly
Circle Turn Gearbox - Check Oil Level
Position machine on a level surface. Lower moldboard to
ground so draw bar is level. Remove oil check plug
(1).
Oil level should be even with bottom of hole. To add oil,
remove breather
(2). Add oil until even with bottom of
check hole.
Install oil check plug and breather.
Tandem Drive Case - Check
Remove oil level check plug (1) on side of tandem case.
Oil level should be even with bottom of hole. Remove fill
plug
(2) and add fluid until level with bottom of check
plug hole.
Repeat for tandem case on other side.
